LD1916 : Kinan 19” Rackmount 16-Port DVI KVM Switch

คุณสมบัติสินค้า:

[ LD1916 ] รีวิว จำหน่าย ราคา Kinan รุ่น LD1916 คือ 19" LCD KVM Switch ที่มี Port DVI สำหรับใช้เชื่อมต่อได้สูงสุดถึง 16 Port และมี 2 Port USB

หมวดหมู่ : KINAN LCD KVM Consoles

แบรนด์ : KINAN

Share

คุณสมบัติย่อ

KINAN KVM SWITCH รุ่น LD1916 คือ 16-Port DVI KVM Switch ขนาด 19 นิ้ว มีการติดตั้งได้ใน Rackmount สำหรับการจัดการควบคุมการเชื่อมต่อคอมพิวเตอร์หลายเครื่องด้วยแพลตฟอร์ม DVI ด้วยคุณสมบัติที่สะดวกและง่ายในการใช้งาน



Hardware Features

  • Integrated rack kvm with 19’’ rackmount keyboard and monitor/touchpad and 16 port KVM switch in a 1U height console
  • Standard DVI connection-Connect to a server or computer via standard DVI connectors
  • LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
  • Support computers with USB and PS/2 keyboard and mouse

Management
  • Convenient computer switching via front panel LEDs, keyboard hotkey combination or on-screen-display (OSD)
  • Auto scan feature for monitoring user-selected computer
  • Broadcast mode--operations simultaneously performed on all selected computers
  • Hot pluggable --add or remove computers without having to power down the switch
  • Quickly select your computer by naming the server or inputting SN number of the server
  • On-Screen Display (OSD) adjustments-Adjust the on-screen image, including: auto adjust, exit, power on/off, brightness, menu, and a power indicator

High Resolution
  • 19" TFT LCD monitor with highlight, high definition and high resolution
  • Resolution is up to 1280x 1024 @60Hz

High Performance Touchpad
  • Touchpad with scroll wheel - Eliminates the need for a separate, external mouse


Keyboard
  • Keyboard Multi-language support--English, Russian, German, French, Spanish, and Korean etc.
  • Full size 99 keys keyboard with integrated number pad

Security
  • Two level password security--only authorized users view and control computers
  • Supports one administrator and four user accounts with a separate profile for each

Wide Compatibility
  • Multiplatform Support-Compatible with Windows, Sun, Unix and Linux
  • Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.

ข้อมูลโดยละเอียดสามารถศึกษาได้จาก Datasheet ที่แถบเมนู Download ที่อยู่ด้านบน



ในชุดอุปกรณ์ประกอบไปด้วย

  • 1x LD1916 LCD KVM Switch
  • 1x Power Cord (Regional)
  • 2x Mounting Rails
  • 16x KVM Cable (CH-1803D; DVI, USB; 1.8m/6ft)
  • 1x Quick Start Guide



ModelLD1916
Computer connectionsDirect16
Max16
Port emulationKeyboard, mouseUSB
LCD monitorLCD modelSXGA TFT
View area19″
Optimum resolution1280×1024@60Hz
Display color16.7 M
Brightness250cd/m²( T y p )
Contrast ratio1000 : 1 ( T y p )
Pixel pitch(mm)0.2928(H) × 0.2928(W)
MouseX/Y resolution>1000 points /inch, (40 points/mm)
Roll wheelSupports scroll wheel function
Keyboard99 keys
(82 keys main keyboard +17 independent small numeric keyboard)
Port selectionFront panel pushbuttons, hotkeys, OSD menu
Input power100V- 240Vac, 50-60Hz, <1.5A
Power consumption25W
Operating temperature0—50 ℃
Store temperature-20—60 ℃
Humidity0—80% RH, non condensing
Net weight13.6kg
Product dimension (W × D × H)448mm×605mm×42.5mm
Package dimension (W × D × H)765mm×615mm×185mm
Optional power input-36V— -72V DC



ในชุดอุปกรณ์ประกอบไปด้วย

  • 1x LD1916 LCD KVM Switch
  • 1x Power Cord (Regional)
  • 2x Mounting Rails
  • 16x KVM Cable (CH-1803D; DVI, USB; 1.8m/6ft)
  • 1x Quick Start Guide
