*HT6824 : Kinan 18.5” 24 Port Widescreen CAT5 LCD KVM over IP Switch 1-Local / 2-Remote Access

คุณสมบัติย่อ


Hardware Features

• Integrated 24 port LCD IP switch with 18.5” LCD screen, keyboard/touchpad in a 1U height console

• Standard Cat5 connection-Connect to a server or computer via standard RJ-45 connectors and Cat5e/6 cables

• LCD module can be opened up to 108 degrees to provide a comfortable viewing angle

• External console port – provides an external VGA, keyboard and mouse port to manage the LCD console from an external console

• Two bus for IP KVM remote control Dual power supply



• Controls up to 24 computers from a single console
• Support 1 local user and 2 remote users, port share mode allows local and remote users to gain access to a server simultaneously
• Easy-to-use switching by browser-based UI interface, hotkeys and pushbuttons
• Support servers with VGA/HDMI/DVI/DP port
• Multiplatform client support - Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
• Supports a graphical interface for intuitive and convenient human-computer interaction- local resolution is up to 1920 x 1080@60Hz
• Supports mouse synchronization mode-automatically synchronizes the local and remote mouse movements
• Video synchronization with local console - EDID information for local console display can be stored in the host module for video resolution optimization
• Keyboard and mouse emulation to ensure the normal booting
• Auto scan feature for monitoring user-selected computer
• Hot pluggable – add or remove computers without having to power down the switch

• Adaptive 10 / 100 / 1000 Mbps network
• WEB browser-based or KVM_Clients remote management
• BIOS-level access
• Video quality and video tolerance can be adjusted to optimize data transfer speed, up to 30 FPS
• Resolutions up to 1920 x 1080@60Hz on remote screen
• Full screen or scalable video display
• Remote users and local users can control the same server synchronously
• Support AES / DES / 3DES encryption
• Support audit function-allows the administrator to audit the device through the system log and operation log
• Support low-bandwidth real-time transmission, the bandwidth is less than 2M
• Exit Macros support
• Configurable user and group permissions for server access and control
• Supports firmware upgrade

ในชุดอุปกรณ์ประกอบไปด้วย

• 1x HT6824 CAT5 IP KVM switch
• 1x Power Cord (Regional)
• 1x Quick Start Guide
• 1x User Manual
• 2x Mounting Rails
• 24x USB KVM Adapter (KCM-1200U)
• 1x Cat5 shield network cable
  1x Ground Lead
