*IPK300 : Kinan One Port KVM Over IP
คุณสมบัติสินค้า:
หมวดหมู่ : KINAN , KVM over IP Switches ,
แบรนด์ : KINAN
รายละเอียดสินค้า
Specifications
Datasheet / Downloads
คุณสมบัติย่อ
Features
- Support 1 individual local console
- Support server with VGA port with USB keyboard and mouse
- Multiplatform support (Windows, Linux, Unix, Mac, Solaris (Sun), Redhat, Ubuntu
- Supports a graphical interface for intuitive and convenient human-computer interaction
- Resolutions is up to: 1920 x1080 @60Hz
- Support mouse synchronization mode-automatically synchronizes the local and remote mouse movements
- Adaptive 10 / 100 / 1000 Mbps network
- WEB browser-based remote management
- BIOS-level access
- Resolution is up to 1920 x 1080@60Hz
- Video quality and video tolerance can be adjusted to optimize data transfer speed, data transfer speed is up to 30 FPS
- Full screen or scalable video display
- Video sharing support
- Support AES / DES / 3DES encryption
- Support audit function-allows the administrator to audit the device through the system log and operation log
- Configurable user and group permissions for server access and control
- Support firmware upgrade
ข้อมูลโดยละเอียดสามารถศึกษาได้จาก Datasheet ที่แถบเมนู Download ที่อยู่ด้านบน
Model | IPK300 | ||
| User | Local | 1 | |
| Remote | 1 | ||
| Computer Connection | 1 | ||
| Connector | Console | Keyboard | USB |
| Mouse | USB | ||
| Screen | VGA | ||
| Network | 1x1000Mbps | ||
| USB2.0 | 1x USB TYPE B 1x USB TYPE A | ||
| Resolution | Local: 1920 x1080 @60Hz Remote: 1920 x1080 @60Hz | ||
| Remote | Remote Control | KVM control (ActiveX) | |
| Management | Web | ||
| Security | DES encrypted | ||
| Power Input | DC12V | ||
| Power Consumption | 5W | ||
| Temperature | 0— 50 ℃ | ||
| Storage Temperature | -20—60 ℃ | ||
| Humidity | 0—80% RH, Non-condensing | ||
| Net Weight | 1.1Kg | ||
| Measurement (W x D x H) | 260mm× 116.6mm×44mm | ||
| Packing (W x D x H) | 330mmx255mm×95mm | ||
