DL1908 : Kinan 19” Rack Mount Dual Rail VGA 8 Port LCD KVM Switch

คุณสมบัติย่อ

Hardware Features

• Integrated KVM Console with 19 LCD monitor, keyboard and touchpad in a dual rail housing
• Standard VGA connection-Connect to a server or computer via standard VGA connectors
• LCD module can be opened up to 108 degrees to provide a comfortable viewing angle
• Support computers with USB and PS/2 keyboard and mouse
• The LCD monitor and keyboard/touch pad modules slide independently of each other


Dual Rail Design

• The LCD panel and keyboard/touchpad modules slide independently of each other, the keyboard/touchpad module slides back to “hide away” when not in use, while the thin profile LCD monitor rotates back, flush against the rack, allowing administrators to easily manage computer.


Management

• Convenient computer switching via front panel LEDs, keyboard hotkey combination or on-screen-display (OSD)
• Auto scan feature for monitoring user-selected computer
• Broadcast mode--operations simultaneously performed on all selected computers
• Hot pluggable --add or remove computers without having to power down the switch
• Quickly select your computer by naming the server or inputting SN number of the server
• On-Screen Display (OSD) adjustments-Adjust the on-screen image, including: auto adjust, exit, power on/off, brightness, and menu


High Resolution

• 19 TFT LCD monitor with highlight, high definition and high resolution
  Resolution is up to 1280 x 1024 60Hz


Daisy-Chain Connection

• By daisy-chaining up to another 31 switches, as many as 256 servers can be controlled from a single console (Compatible Kinan Rack KVM Switches: XM0108, XM0116, XU0108, XU0116)


Security

• Two level password security--only authorized users view and control computers
• Supports one administrator and four user accounts with a separate profile for each


High Performance Touchpad

• Touchpad with scroll wheel - Eliminates the need for a separate, external mouse


Keyboard

• Multi-language support--English, Russian, German, French, Spanish, and Korean etc.
• Full size 99 keys keyboard with integrated number pad


Wide Compatibility

• Multiplatform Support-Compatible with Windows, Linux, Mac and Sun
• Supports servers form Lenovo, HUA WEI, HP, IBM, Cisco and Dell, etc.



ข้อมูลโดยละเอียดสามารถศึกษาได้จาก Datasheet ที่แถบเมนู Download ที่อยู่ด้านบน

ในชุดอุปกรณ์ประกอบไปด้วย

• 1x DL1908 LCD KVM Switch
• 1x Power Cord (Regional)
• 2x Mounting Rails
• 8x KVM Cable (CH1802U; VGA, USB; 1.8m/6ft)
• 1x Quick Start Guide
